V419 : Commscope Coaxial Cables 2275V WHRL RG6 60 1000 ft

Commscope Coaxial Cables 2275V WHRL RG6 60 1000
RG 6 Type 60% Braid Plenum Video Coaxial Cable, white jacket, 1000 ft (305 m) reel

Product Classification
– Portfolio : CommScope
– Product Type : Coaxial video cable

Construction Materials
– Construction Type Non-armored
– Center Conductor Material Copper-clad steel wire
– Dielectric Material Foam FEP
– Shield (Braid) Coverage 60 %
– Shield (Braid) Gauge 34 AWG
– Shield (Braid) Material Aluminum
– Shield (Tape) Material Aluminum/Poly
– Jacket Material PVC

Dimensions
– Cable Length 305 m / 1000 ft
– Cable Weight 26.00 lb/kft
– Diameter Over Dielectric 4.3180 mm / 0.1700 in
– Diameter Over Jacket Tolerance ±0.006 in
– Diameter Over Jacket, nominal 6.071 mm / 0.239 in
– Diameter Over Shield (Tape) 4.521 mm / 0.178 in
– Jacket Thickness 0.381 mm / 0.015 in
– Jacket Thickness, minimum spot 0.254 mm / 0.010 in

Electrical Specifications
– Capacitance 50.9 pF/m / 15.5 pF/ft
– Characteristic Impedance 75 ohm
– Characteristic Impedance Tolerance ±3 ohm
– Conductor dc Resistance 28.60 ohms/kft
– Dielectric Strength, conductor to shield 2000 Vdc
– Jacket Spark Test Voltage 2500 Vac
– Nominal Velocity of Propagation (NVP) 84 %
– Shield dc Resistance 9.00 ohms/kft
– Structural Return Loss 15 dB @ 1000–3000 MHz / 20 dB @ 5–1000 MHz
– Structural Return Loss Test Method 100% Swept Tested

Environmental Specifications
– Environmental Space Plenum
– Flame Test Method CMP
– Safety Standard cETL ETL
– UL Temperature Rating 60 °C / 140 °F

General Specifications
– Cable Type Series 6
– Jacket Color White
– Supported Application Video
– Product Number 2275V
– Center Conductor Gauge 18 AWG
– Center Conductor Type Solid
– Packaging Type Reel

Mechanical Specifications
– Minimum Bend Radius, loaded 20 times
– Minimum Bend Radius, unloaded 10 times
